Pressure Sensor Silicone Seal Ring Molding Machine Chip-Level Seal Ring

Name: Pressure Sensor Silicone Seal Ring Molding Machine ChipLevel Seal Ring
Brand: Better
Price: 22000 USD

China Pressure Sensor Silicone Seal Ring Molding Machine Chip-Level Seal Ring wholesale

Volume Ratio % : 1:1

Key Selling Points : Energy Saving

Core Components : Motor, Pump, PLC, Pressure vessel

Brand Name : Better

Model Number : Better 615

Certification : CE、ISO

Place of Origin : GuangZhou，China

MOQ : 1 SET

Price : USD22000-USD45000per set

Payment Terms : T/T

Supply Ability : 25 sets per month

Delivery Time : 30 days

Packaging Details : Wooden case

Contact Now

Pressure Sensor Silicone Seal Ring Molding Machine Chip-Level Seal Ring

High-Precision LSR Dosing System

Advanced liquid silicone rubber dosing system engineered for precision manufacturing of pressure sensor silicone seal rings at chip-level specifications.

All components processed with imported equipment using original packaging to ensure manufacturing accuracy
Core parts imported from Europe and America for enhanced stability and extended service life
Convenient maintenance design with easily disassembled displacement pump device
Long-life service sealing elements for reliable operation
Function guarantee with external valve system
Detachable mixer for flexible configuration
Material shortage and over-pressure alarm safety devices
Reproducible color adjustment capabilities
Optimized coating through special material barrel supporting disk
Material barrel emptying alarm system
Customizable options for specific application requirements
Compliance with international and European standards
Flexible material handling with 200-liter to 20-liter barrel conversion
Hard metal ball valve and high-speed steel piston rod for handling various viscosity materials
Coolable mixing section for temperature control
Colorant addition and metering device
Continuous feeding pump operation with material assistance
Pressure gauge display for mixed materials monitoring

The system precisely meters two components in desired ratios through a specialized delivery system to the injection unit. Designed to integrate seamlessly with existing LSR delivery equipment or as part of a complete turn-key LSR solution.

Technical Specifications

Characteristics	Solid silicone to LSR
Item No	Better 615
Shot Volume	0 - 1500g
Material Capacity	20L / 200L
Ratio	1:1
Motor Source	Hydraulic Servo
Dimensions	1920 x 1030 x 1800 mm
Weight	1200 KG
Mix Mode	Static + Dynamic
Work Style	Plunger Pump
Application	Universal Compatibility

Advanced Technology Features

Premium design with high cost-performance, compatible with both 20L and 200L drums
PLC control panel for high efficiency and user convenience with stable system operation
High-precision material measurement with synchronous structural design for balanced pressure output
Pressure sensor configuration with ultra-pressure and material alarm systems
Position transducer monitoring with A and B pressure regulating valves for precise 1:1 ratio output
Full hydraulic system with international brand components ensuring stability and reliability
Effective prevention of leakage and contamination
Pneumatic control valve and color pump installation on host for easy disassembly and positioning
Interchangeable compatibility with various machines to reduce color replacement frequency and waste
Easy cleaning, energy efficiency, high performance, and low noise operation
Suitable for transition applications of various dual-component liquid silicone
High production efficiency when integrated with LSR injection molding machines
Compatible with injection machinery from multiple brands
